1. 1:1 design, fixed quilting frame, quilting head & saddler moving with X & Y direction respectively for quilting work, Minimized the machine size, resolved the traditional 2 times or 4 times moving frame type machine floor plan occupation problem. Increased the utilization of factory area.
2. Maximum Speed: 3000RPM, suggested working speed at 2500-2800RPM.
3. Supporting belt equipped, able to rigid the material during quilting process, avoid material sinking.
4. Specially designed quilting head, presser foot with individual driving, suitable for quilting material of various thickness.
5. Auto-lifting machine head, after completed a quilting work, machine head is lifted up for easy replacement of new material frame.
6. Extendable quilting frame, able to adjust the desirable size of quilting freely.
7. Full servo motor control, providing powerful and accurate driving force, greatly improved quilting precision.
8. High precision processed stand ensures stable needle & hook alignment and longer service lifetime of rotary hook.
9. Original international brand large rotary hook and bobbin case.
10. Automatic thread broken detection function, the machine will stop after thread broken and return to disconnection point to continue quilting after manually threading.
11. Optional: Extendable automatic frame changer ( Adjusting the device width by manual, and easy for material loading when quilting small piece products.) or, easy frame changer.
Configuration
(The final configuration is subject to the manufacturer’s factory standard)
